Liquid Controls POD1 - Specifications

Pulse Output Device
9
Get the latest PDF manual:
https://www.lcmeter.com/resources/technical/manuals
Mobile/online version of this manual:
https://www.lcmeter.com/manuals
Specifications
Voltage
· 9 to 30 VDC
· POD5 has a 5 VDC minimum but is not IECEx approved
Current Supply
maximum
· 50 mA
Output Signal
Resolution
· 100 pulses per channel per revolution, unscaled (see the Output
Signal Resolutions table in General Information )
Square Wave
· Single channel output – Channel A or channel B
· Quadrature channel output – Channel A and channel
Pulse Timing
· Nominal 50% on and 50% off
Rise/Fall Time of
Pulse
· < 5 µ s
Output
· Current sinking 100 mA maximum in “ON” state
· V+ supply @ 2.2 KΩ in “OFF” state.
· Optional open-drain FET (Field-Effect Transistor).
· FET rating (drain to source voltage) 30 VDC maximum
Pulse
Transmission
Distance
· 5,000 feet (1,524 meters)
Pulse Output
Fidelity
· ISO 6551 Level A
· API MPMS Chapter 5.5; Level A
· OIML R117-1
· Measurement Canada’s SVM-1
Materials of
Construction
· Aluminum Alloy ADC12
· Powder Coat: Corro-Coat PE 74-141 Polyester
Cable Entry
· ½"-14 NPT
