23
6.3 Flush the exhaust
Note
Before any longer operational pause (longer than 0.5 hours)
rinse the exhaust with water so that no dried dirt is stuck in the
system.
Switch on the saw blade and joint cutters cooling water
(do not saw).
Switch on exhaust.
Flush until the exhaust hose is running clear water.
6.4 Remove the exhaust
Attention!
The refit must be done by two people.
Transport wheels and the support feet are lowered by the
cotter pins (Pos. 34.1)
One person holds the handles (Pos. 33)
A second person pulls the plug (Pos. 34)
Now the waste water suction can be set onto the wheels
(tilted)
Disconnect the HD lines to the floor cutter
Mount the water hoses to the other side
Remove the adapter rails to the waste water suction
Mount on the opposite side
Remove the protective hood and saw blade from the right
side (see 3.3)
Mount the saw blade on the left side
(see 3.3)
Mount the saw blade protective hood on the left side
32
34
34.1
33
