LA-140 – Mounting your Radiator
8
Connect CAT-5 and Coaxial cables to appropriate locations on radiator.
Connect CAT-5 and Coaxial cables
7
The radiator has a safety cable attached to the top of the swing arm. This cable must be attached to a secure base to
prevent the radiator from falling in the event of a mounting hardware component failing. Possible injury to persons
and damage to the radiator is prevented by securely attaching this cable to a base.
Attach Safety Mounting Cable
attach to a secure base
