LiteOn EVO6000 Series User Manual

96
Appendix UL Descriotion
1) “Maximum surrounding air temperature rating of 50ºC”
2) “The drive is suitable for use in a circuit capable of delivering not more than
5,000 rms symmetrical amperes, Maximum, 220 V for 200 V three-phase, 240 V for
200 V single-phase, 480 V for 400 V three-phase. ”
These devices are only intended to be installed with the following branch circuit
fuse.
400V 3Φ
Input Current I (A)
Line Fuse
I (A)
Bussmann P/N
0.4kW (0.5 HP)
2.7
5
FRS-R-5
0.75kW (1 HP)
4.4
10
FRS-R-10
1.5kW (2 HP)
6.7
10
FRS-R-10
2.2kW (3 HP)
9.3
15
FRS-R-15
3.7kW (5 HP)
12.9
20
FRS-R-20
200V 1Φ
Input Current I (A)
Line Fuse
I (A)
Bussmann P/N
0.2kW (0.25 HP)
3.6
6
FRS-R-6
0.4kW (0.5 HP)
7.4
10
FRS-R-10
0.75kW (1 HP)
13.5
20
FRS-R-20
1.5kW (2 HP)
24
30
FRS-R-30
2.2kW (3 HP)
33
40
FRS-R-40
200V 3Φ
Input Current I (A)
Line Fuse
I (A)
Bussmann P/N
0.2kW (0.25 HP)
2.2
5
FRS-R-5
0.4kW (0.5 HP)
3.7
5
FRS-R-5
0.75kW (1 HP)
6.6
10
FRS-R-10
1.5kW (2 HP)
10.5
15
FRS-R-15
2.2kW (3 HP)
14.8
20
FRS-R-20
3.7kW (5 HP)
21.5
30
FRS-R-30
3) “The drive must be installed in a Pollution 2 environment with clean air
according to enclosure classification. Cooling air must be clean, free from
corrosive materials and electrically conductive dust.”
4) “Integral solid state short circuit protection does not provide branch circuit
protection. Branch circuit protection must be provided in accordance with the
National Electrical Code and any additional local codes”, or the equivalent.
5) “Solid State motor overload protection level in percent of full-load current
(150% FLA).”
6) “Overtemperature protection is not provided by the drive.”
7) Use Copper Conductors rated 60/75C.
8) Type of electrical supply system (3WYE) to which the drive shall be connected
(Olny for three phase series)
