LiteOn EVO600043S2D2E20F Quick Start Guide

11
Parameter Function
Over torque/torque shortage detection, multi-speed operation,
acceleration/deceleration switching, instantaneous power failure restart,
speed search, S-curve acceleration/deceleration, 3-wire sequential
control, motor parameter automatic detection, cooling fan ON/OFF
function, sliding Differential compensation, torque compensation,
frequency jump, frequency command upper and lower limit setting, DC
braking at start/stop, PID control, fault retry, automatic voltage
adjustment.
Operating Environment
Area of Use
Indoor without corrosive gas/liquid or flammable gas/liquid/oil mist/dust
Ambient Temperature
-10℃ to +50℃, below 90% RH without froze or condensation
Storage Temperature
-20℃ to +60℃
Altitude
Up to 1000 meters
Shock
Below 9.8 m/s
2
(10 to 20Hz), below 5.9 m/s
2
(20 to 55Hz)
Enclosure
IP20
I/O
Analog Input (AI)
1 point (AI: 0 to 5V, 0 to 10V (12 bits), 0 or 4 to 20mA(11 bits))
Digital Input (DI)
6 points
Analog Output (AO)
1 point (FM: 0 to 10V (10bits))
Digital Output (DO)
0
Relay Ｏutput (RO)
1 point
Communications
Modbus (RS-485 port)
Option Card
Profibus-DP, CANopen, DeviceNet
Short-Circuit Current
The drive is suitable for use in a circuit capable of delivering not more
than 5,000 rms symmetrical amperes, 480 Volts Maximum.
Certificate
UL 508C, CSA C22.2 no .274, IEC 61800-5-1, IEC 61800-3
*1. Results tested in labs
