2.8.2 Installing Input Fuses
Installing fuses on the drive input side is recommended to prevent internal short circuit. Select
the suitable fuses below or the branch circuit protection in compliance with local electrician
regulations.
400V Model Three Phase
Input Current I (A)
Line Fuse
I (A)
Bussmann P/N
0.4kW (0.5 HP)
2.7
5
FRS-R-5
0.75kW (1 HP)
4.4
10
FRS-R-10
1.5kW (2 HP)
6.7
10
FRS-R-10
2.2kW (3 HP)
9.3
15
FRS-R-15
3.7kW (5 HP)
12.9
20
FRS-R-20
200V Model Single phase
Input Current I (A)
Line Fuse
I (A)
Bussmann P/N
0.2kW (0.25 HP)
3.6
6
FRS-R-6
0.4kW (0.5 HP)
7.4
10
FRS-R-10
0.75kW (1 HP)
13.5
20
FRS-R-20
1.5kW (2 HP)
24
30
FRS-R-30
2.2kW (3 HP)
33
40
FRS-R-40
200V Model Three Phase
Input Current I (A)
Line Fuse
I (A)
Bussmann P/N
0.2kW (0.25 HP)
2.2
5
FRS-R-5
0.4kW (0.5 HP)
3.7
5
FRS-R-5
0.75kW (1 HP)
6.6
10
FRS-R-10
1.5kW (2 HP)
10.5
15
FRS-R-15
2.2kW (3 HP)
14.8
20
FRS-R-20
3.7kW (5 HP)
21.5
30
FRS-R-30
