LiteOn EVO600043S2D2E20F Quick Start Guide

90
6.3 Operation Errors
Table 6.3 Error Displays, Causes, and Possible Solutions
Keypad
Display
Error Name
Cause
Possible Solution
oE02
Parameter Range
Setting Error
Parameters are set outside of
the possible setting range
1. Set the parameters to the
proper values
2. Reset the drive
oE03
Multi-Function
Input Selection
Error
1. Either of Up command and
Down command is not set
(E1-□□= 10 or 11 )
2. Either of Up command 2
and Down command 2 is not
set (E1-□□=12 or 13)
Properly assign both of the UP and
Down commands to the multi-
function input terminal.
oE04
3-Wire Sequence
Control Setting
Error
Multi-Function input
terminals S1 and S2 are
assigned to E1-□□= 2 (3-Wire
Sequence)
Do not assign multi-function input
terminals S1 and S2 to E1-□□= 2 (3 –
Wire Sequence)
oE05
Communication
Error
oE09
PID Control
Selection Fault
(When b5-00 (PID
Control Setting)= 1
to 4)
1. Contradictory settings
· b5-14 (PID Sleep Start
Level) is not set to 0.0
· b1-02 (Stopping Method
Selection) is set to 2 (DC
Braking to Stop) or 3 (Coast
to Stop with Timer)
2. L2-01 (Frequency
Command Lower Limit)≠0
when b5-00 = 1 or 2 (PID
Control Enabled)
3. b5-10 (PID Output Reverse
Selection) = 1 (Reverse
Enabled) when b5-00 = 1 or
2
4. L2-01 ≠ 0 when b5-00 = 3
or 4
1. Correct the parameter setting.
2. Correct the parameter setting.
3. Correct the parameter setting.
4. Correct the parameter setting.
oE10
V/F Data Setting
Error
V/F parameters setting
incorrect
Correct the setting in d1-02, d1-04,
d1-06, d1-08 and d1-09.
