LiteOn EVO600043S2D2E20F Quick Start Guide

89
Keypad
Display
Fault Name
Cause
Possible Solution
FbH
PID Feedback High
1. Incorrect parameter
settings
2. Incorrect PID feedback
wiring
3. Feedback sensor
malfunction
1. Reset b5-22 and b5-23
2. Correct the wiring
3. Check the sensor
FbL
PID Feedback Low
1. Incorrect parameter
settings
2. Incorrect PID feedback
wiring
3. Feedback sensor
malfunction
1. Reset b5-12 and b5-13
2. Correct the wiring
3. Check the sensor
bUS
Retain
CE
Modbus
Communication Error
1. Incorrect wiring
2. Communication data error
caused by noise
1. Correct the wiring
»Check short circuits and
disconnected cables, repair if
necessary
2. Check possible solution to
suppress the noise
CF
Retain
Err
Retain
JoGE
FJOG/ RJOG Input
Error
A FJOG and RJOG Run
commands are received at
the same time
Check the Run command from
the external source for Fjog/Rjog
ACE
A1 Input signal is
missing
1. A1 Input signal is missing
1. Check the analog signal wiring
2. Confirm the E3-04 parameter
setting
FBPL
(water pump function)
water shortage failure
1. The feedback pressure is
less than the water shortage
detection value (F1-09) and
lasts for a period of time (F1-
11)
2. The output current is less
than the water shortage
detection value (F1-10) and
lasts for a while (F1-11)
1. Insufficient water / water
shortage
2. Judging the level value is too
large
3. Detection time is too short
