LiteOn EVO600043S2D2E20F Quick Start Guide

52
Parameter
Name
Description
Setting Range
d2-10
Motor Rated
Capacity
Sets the motor rated capacity. This will be set
automatically during Auto-Tuning. (1HP = 0.746
kW)
Default: o2-03
Min.: 0.00 kW
Max.: 650.0kW
Group E, Multi-Function Terminals
E1: Multi-Function Digital Inputs
E1-00
Terminal S1
Function Selection
0 : 2-Wire Sequence Control (Forward/Stop) / 3-
Wire Sequence Control (Stop)
1 : 2-Wire Sequence Control (Reverse/Stop) / 3-
Wire Sequence Control (Stop)
2 : 3-Wire Sequence
3 : Local/Remote Selection
5 to 8: Multi-Step Speed Command 1 to 4
9 : Jog Frequency
10 : Up Command
11: Down Command
12: Up 2 Command
13: Down 2 Command
14, 15: FJOG/RJOG Command
16: Acc./Dec. Time Selection 1
18: Acc./Dec. Ramp Hold
19∶ Baseblock Command (Normal Open)
20∶ Retain
21: Fast Stop (Normal Open)
22: Fast Stop
23 to 38 : External Fault
39: Fault Reset
40 : oH2 (AC drive Overheat Alarm)
45: Communication Mode
46: PID Disable
47: PID Integral Reset
48: PID Integral Hold
49: PID Soft-Start On/Off
50: PID Input Characteristics Switch
52: Timer Input
53, 54, 55: Offset Frequency 1/ 2/ 3
58/59: Retain
60: Program Lockout
61: Analog Frequency Command Hold
62: Retain
Default : 0
Min.: 0
Max.: 69
E1-01
Terminal S2
Function Selection
Default : 1
Min.: 0
Max.: 69
E1-02
Terminal S3
Function Selection
Default : 23
Min.: 0
Max.: 69
E1-03
Terminal S4
Function Selection
Default : 39
Min.: 0
Max.: 69
E1-04
Terminal S5
Function Selection
Default : 9
Min.: 0
Max.: 69
E1-05
Terminal S6
Function Selection
Default : 19
Min.: 0
Max.: 69
