Keeping track of time from run or power up is
determined by o4-01. The maximum number
displayed is 9999, after which the value will be
counted from 0.
Lights all segments of the LED to verify that the
display is
working properly
Displays the peak current value during operation
Peak Hold Output
Frequency
Displays the output frequency when the peak
current displayed in U3-10 occurred.
Motor Overload
Estimate (oL1)
Displays the value of the motor overload
detection accumulator. An oL1 will be triggered
when reaching 100%.
Frequency
Command Source
Selection
Displays the source for the frequency command
as XY-nn.
X: Command Used
1: Command 1
Y-nn: Frequency Command Source
0-01: Keypad
1-01: Analog input (Terminal AI 1)
2-02 to 2-16: Multi-step speed command
2-17: Jog frequency command
3-01: PID frequency command
4-01: Terminal UP/ DOWN
5-01: Modbus communication
Run Command
Source Selection
Displays the source for the frequency command
as XY-nn.
XY-nn=00-00: Local
X: Command Used
1: Command 1
Y-nn: Command Source
0-00: Keypad
1-00: Control Circuit Terminal (Sequence
Control Input)
2-00: Modbus communication
Drive Overload
Estimate (oL2)
Displays the value of the drive overload detection
accumulator. An oL2 will be triggered when
reaching 100%.
Displays the PID feedback value as a percentage
of the maximum output frequency.
Displays the PID input value as a percentage of
