LiteOn EVO600043S2D2E20F Quick Start Guide

76
Keypad
Display
Fault Name
Cause
Possible Solution
Drive current
exceeded the level
of over current
warning (150% of
the rated current)
2. Deceleration and
acceleration times
are too short
3.The drive is
attempting to run a
motor greater than
the maximum
allowable capacity,
or a special-
purpose motor is
being used
4.The current level
went up because of
Speed Search while
attempting to
perform a fault
restart or after a
momentary power
loss
rating
2. Calculate the torque
required during
acceleration and the
inertia
»Take the following
steps if the torque level
is not right for the load
· Increase the settings
for acceleration and
deceleration time (C1-
00 to C1-03)
· Use a drive of higher
rating
3. Check the motor
capacity
· Make sure the motor
capacity is right for the
drive rating.
4. During a momentary
power loss or an
attempt to reset a fault,
the alarm is displayed.
However, there is no
need to take any action
because the fault
display will disappear
shortly
DNE
Driver Enable
1. Multi-function
contact input is set to
69/169, but the
contact input status is
incorrect
2. The multi-function
contact input is
incorrect
1. Multi-function contact
input is set to 69 and
switched on.
2. Multi-function contact
input is set to 169 and
switched off
AnL
Simulation A2
input signal is lost
1. Simulation A2
input signal is lost
1. Check the simulation
signal wiring
2. Check the E3-10
parameter settings
ES
Emergency Stop
1. Emergency stop is
1. Turn off the
