Hoist “C” Dimension
Capacity Standard Size Limit
(tons) (in.) (in.)
.75 1
3
/
16
1
5
/
16
1.5 1
13
/
32
1
9
/
16
31
21
/
32
1
13
/
16
62
3
/
64
2
1
/
4
NOTE: Limit *C (in.) are the maximum permissible dimensions of
the hooks, which are about 10% wider than the standard hook
openings.
Figure 11 - Hook
Inspection
OPTIONAL OVERLOAD PROTECTION
A standard LMSC Lever Hoist can be converted to a unit with the overload protection by
replacing Reference No. 14 (See Figures 15 & 16) with Reference No. 80 (See Figure 12).
Refer to chart below for the appropriate load limiter for your capacity hoists.
The load limiter may require adjustment when it slips at or below rated load. Please refer to
chart below for the correct torque setting for the load limiter. Only adjust the load limiter by
Reference No. 110. If the load limiter cannot be corrected by adjusting the torque setting or
if any of the parts are damaged then the load limiter must be replaced. A special tool is
required to adjust Item 110 properly (Contact Factory).
Hoist Torque Range
Model (foot-lbs)
LMSC1500 28 - 32
LMSC3000 59 - 66
LMSC6000 77 - 85
LMSC12000 77 - 85
NOTE: Excessive torque will damage the load limiter
and could cause equipment damage or personal
injury.
RReeff.. ..7755 TToonn 11..55 TToonn 33 TToonn 66 TToonn
N
Noo.. DDeessccrriippttiioonn PPaarrtt NNoo.. PPaarrtt NNoo.. PPaarrtt NNoo.. PPaarrtt NNoo.. QQttyy
80 Overload IRB5080U KRB5080U NRB5080U QRB5080U 1
Protection Device
110
80
Figure 12 -
Overload
Protection
Device
Table 2 - Torque Range for Item 110
