5.3 Factory Settings
The factory settings of COM port are as follows:
Baud rate: 19200 bps
Data bit: 8
Parity: none
Stop bit: 1
Flow control: None
Others: please refer to section 7.8 AT Command Set.
6. Installation
6.1 Hardware Structure
The gure below is an outline of the adapter.
1. Link LED 2. Data LED 3. Power LED 4. Mini USB
connector
5. RS232 connector 6. Slide Switch 7. Reset Button
6.2 Reset Button
By pressing the Reset button, you can:
Disconnect and reconnect a wireless connection (after a short press).
Restore the factory settings (after over three seconds’ press).
4
