Operating Power DC24V ± 15 %
Output Transistor output( 100mA )
Max. Output Current 100mA (transistor)
Power Consumption < 3W
Ambient Temp.
-10 ℃ ～ 55 ℃
Humidity
20 ℃ , RH ≤ 95% （ no condensated water ）
Response Time 3ms ~ 18ms
Insulation Resistance > 100M Ω
Dielectric Strength AC1500V , 60s
Anti-interference to Light 10000Lux (incidence angle ≥ 5 ° )
Light Source Infrared, 940nm
Housing Sensor:aluminum alloy
Sealing Sensor:IP65
Resolution 1 9 mm , 2 9 mm , 4 9 mm
Protection Range 400 ~ 3500mm
Protection Height H= ( xx-1 ) × pitch, xx : beams
4.Specification
It consists of three parts which separated by"-",the first part means
the NO. of light beams,the second means light pitch,third part means the
output type,please remark it in order if the special controller required.
2
