9
LOADRITE™ LP950 Printer User Guide
Baud Rate
1200 or 9600 baud set by internal jumper.
Data Buffer
1 line (24 character) printing of line
initiated when buffer full (24 char.) or LF,
CR, CRLF received. CR and LF are
treated as a CRLF pair.
Power Requirements
11.2 to 32V DC.
Average Current when printing:
0.75A @ 12V DC input
0.4A @ 24V DC input.
Peak Current when printing:
3.0A @ 12V DC input.
1.3A @ 24V DC input.
Standby Current:
100mA max.
40mA typ. @ 24V.
Power Input Protection
Series diode to protect against reverse
voltage. Input filter and high voltage pre-
regular into switch-mode main regular to
protect against “load-dump” and
automotive transients.
