Lockly SECURE - Section 2 - Product Overview

1 " - 2"
(35mm - 50mm)
2 "
54mm
1"
25mm
Backset
2
" (60mm)
or 2
" (70mm)
IMPORTANT NOTICE
* You are not required to drill an extra hole on your door. We have provided 3M double sided
tape for you to help stabilize the lock during installation. Only drill a hole if you wish to have
added stability. Please refer to the provided template for drilling if needed.
*
Measure and confirm your door is
between
1 " - 2" ( 35mm - 50mm).
Measure and confirm the hole in the
door is
2 " (54mm).
Measure and confirm that the
backset is between
2 " (60mm) to
2 " (70mm).
Measure and confirm that hole in the
door edge is 1” (25mm).
1.3
1.4
1.5
1.6
