LockMaster DKC400UY - Parts List

MODEL: DKC400UY
COMPONENT
DESCRIPTION
COMPONENT
MANUFACTURER
MFR’S PART NO. QUANTITY
1
Cover
LockMaster
tr3cov1 1
2
Set Phillips screw
LockMaster
tr3sps2 1
3
½ h.p. Motor
LockMaster
tr3mot3 1
4
Limit magnets
LockMaster
tr3lm4 2
5
Control board
LockMaster
tr3c/b5 1
6
Capacitor
LockMaster
tr3cap6 1
7
Gear racks 2.3 ft.
LockMaster
tr3gr7 5
8
Plastic clip
LockMaster
tr3pc8 4
9
Base plate for receiver/
limit switch sensor
LockMaster
tr3bp9 1
10
Base plate for control board
LockMaster
tr3bp10 1
11
Plastic clip
LockMaster
tr3pc11 4
12
Receiver
LockMaster
tr3rec12 1
13
Large bracket for magnet (open limit)
LockMaster
tr3lbol13 1
14
Limit switch sensor
LockMaster
tr3ls14 1
15
19 tooth Sprocket
LockMaster
tr319spr15 1
16
C-Clamp
LockMaster
tr3ccl16 1
17
Motor housing
LockMaster
tr3mh17 1
18
Small bracket for magnet (close limit)
LockMaster
tr3sbcl18 1
19
Mounting base
LockMaster
tr3mb19 1
20
Manual release keys
LockMaster
tr3keys20 2
