Accessories Connection (Optional)
There is connection wire Terminal on the PCB board in the control box.
The function is as follows:
（1）BAT(+) BAT(-) for back up battery
The user can connect backup battery (optional) by both BAT (+) and BAT (-) terminals.
By installing a 24V/5AH battery (optional), the SWING GATE OPENER will be possible to carry out
approx. 50 emergency operations without power supply. The battery should be always connected to the
terminal to keep it charged. Before using the system with only the battery it shall be first charged for at
least 24 hours.
* If more operation cycles are required during power failure, the user may choose battery of bigger
capacity.
* The user may use a solar panel (optional) to maintain charging the battery power even there is no
power supply.
（2）O/S/C for Push Button
The user can connect push button (optional) by both terminals. The push button can be installed at any
safety place you prefer, so that the user may open/close the gate conveniently.
（3）Alarm Lamp
This device is foreseen by all safety EEC norms, and it has to be installed in a visible position.
The device operates at LOW VOLTAGE and a 24V 10W Bulb.
Caution: Never exceed this power as there might be the risk of damaging circuits.
Operation: The intermittent signal comes from the control unit. The activation starts 2 seconds before
each operation.
The blinking is slow when the gate opens or closes and faster when gate stop/reverse in case of
obstruction.
(4) Solar Panel
The solar panel should be connected with the back up battery directly and it should not be installed
before the back up battery is installed. With the solar panel, the back up battery can be charged both by
the control box from AC power and directly by solar panel.
The 30W solar panel consists of three 10W panels by parallel connection.
The 5AH battery (LM125/5) is standby power source, which is recommended for use where power failure
is rare. When equipped, please use the 5AH battery adaptor (LM135).
The 5AH battery with 10W solar panel (LM109) is also standby power source, which is recommended for
use where power failure is frequent. When equipped, please do use the 5AH battery adaptor (LM135/5).
The 12AH battery（LM125/12）with 30W solar panel（LM109) can be used as main power source, which
is recommended for use where AC power is unavailable. When equipped, please do use the 12AH
battery adaptor (LM135/12).
The provided battery is 12 volt each cell. The user is
required to connect two 12V battery cells in series to
function as a 24V standby power source.
Connect the 24V battery directly with the PCB. Refer to
Page 17 Connecting Opener Power Cables.
Directly connecting the wires from the actuator (motor)
to other power source is forbidden.
