Locknetics 101+ - Indicators and Signals

101+ DELAYED EGRESS
MAGNETIC LOCKING SYSTEM
20
FORM 10111 Rev. C 04/11/2002
DESCRIPTION OF INDICATORS
CONDITION LED INDICATOR AUDIBLE
ALARM RELAY
STATE (TERM.7&8)
STANDARD FEATURES
LOCK SECURE OFF OFF OPEN
LEGAL RELEASE INPUT STEADY GREEN OFF OPEN
LOW INPUT VOLTAGE OFF SLOW BEEP OPEN
DURING NUISANCE DELAY STEADY YELLOW OFF(DEFAULT)
(SET BY SW4-8)
OPEN
DURING DELAYED EGRESS FLASHING RED BEEPING CLOSED
AFTER DELAYED EGRESS STEADY GREEN STEADY TONE CLOSED
ANTI-TAMPER ALARM
IF LOCK COVER IS REMOVED
(ON MASTER UNIT ONLY –
SLAVE ATS HAS FLYING LEADS)
STEADY
RED
STEADY
TONE
CLOSED
SWITCH SELECTABLE FEATURES
SW4-5 “ON” =UNLOCK ALARM
WHENEVER LOCK IS UNLOCKED
STEADY
GREEN
STEADY
TONE
OPEN
SW4-8 “ON” = HORN WILL SOUND
DURING NUISANCE ALERT
STEADY
YELLOW
ON OPEN
OPTIONAL SWITCH SELECTABLE FEATURES
SEC (SECURITY ALARM OPTION) REQUIRED
SW4-6 “ON” DOOR PROPPED
OPEN ALARM
DOOR IS HELD OPEN PAST
RELOCK TIME
FLASHING
GREEN
BEEPING CLOSED
SW4-6 “ON” DOOR FORCED
OPEN ALARM
DOOR OPENED WITHOUT VALID
RELEASE SIGNAL
FLASHING
RED
BEEPING CLOSED
PROGRAMMING INDICATIONS
RELOCK DELAY PROGRAMMING
ACTIVE
FLASHING
GREEN
OFF OPEN
DOOR PROPPED OPEN DELAY FLASHING YELLOW OFF OPEN
WHILE PRESSING SW3 0R SW2
TO SET RELOCK AND DOOR
PROPPED DELAYS
RED CHIRP OPEN
NUISANCE DELAY
PROGRAMMING ACTIVE
FLASHING RED OFF OPEN
WHILE PRESSING SW2 TO SET
NUISANCE DELAY
GREEN CHIRP OPEN
TABLE OF INDICATORS (LED/AUDIBLE)
The table below is intended to provide all possible indications and states which can be encountered under normal operation. Note
that some conditions or features are only available on certain models or when certain options are included.
