Locknetics 101+ - Dipswitch Settings

101+ DELAYED EGRESS
MAGNETIC LOCKING SYSTEM
9
FORM 10111 Rev. C 04/11/2002
8
ONSW-4 DIPSWITCH SETTINGS OFF
7
6
5
4
3
2
3
2
3
2
1
DISABLED
DISABLED
DISABLED
DISABLED
DISABLED
30 SEC.
ENABLED
ENABLED
ENABLEDNUISANCE ALERT: Horn sounds when door pushed to alert people that door is armed. Avoids false alarms.
AUTOMATIC RELOCK: Door locks upon power up or after fire alarm. If set to OFF: manual reset required.
DOOR FORCED / DOOR PROPPED ALARM (SEC OPTION ONLY)
UNLOCK ALERT: Horn sounds whenever door is unlocked (and still has power applied to it).
ANTI-TAILGATE (SEC OPTION ONLY): When door closes it immediately relocks (cancels time delay).
EGRESS DELAY TIME: This is the time that the door will remain locked and in alarm before it unlocks.
SWITCH #
ENABLED
ENABLED
15 SEC.
x
x
x
x
x
x
3
2
x
x
x
x
BY ON-BOARD ROCKER SWITCH ONLY (DEFAULT)
BY ROCKER SWITCH OR AUXILIARY INPUT
BY ROCKER SWITCH AND AUXILIARY INPUT
DELAYED EGRESS DISABLED.
CONFIGURE HOW
THE DELAYED
EGRESS EVENT IS TO
BE TRIGGERED,
USING DIPSWITCHES
2 & 3
SW-1
SW-1 TO RIGHT FOR N.O. OR NO CONNECTION:
SW-1 TO LEFT FOR N.C. CONNECTION:
SW-1 FIRE ALARM INPUT:
To configure interface to terminals 3&4
on main terminal block.
CONFIGURE FIRE ALARM INTERFACE DIPSWITCH (SW-1) FOR CORRECT TYPE OF INPUT.
A dry contact is required. It can be normally open or normally closed. If no direct connection is to be made, configure the input for normally open (SW-1 to RIGHT).
CONFIGURE THE SW-4 DIPSWITCHES TO SET THE FUNCTIONS OF THE SYSTEM.
Power should not be applied at this time. Note that dipswitches 4 and 6 are specifically for the SEC option. Also note that dipswitch 7 must be “on” for the lock to auto-
matically lock when powered up, or after a fire alarm condition. If it is off, the lock will remain unlocked, with the LED green, when power is applied. In order to lock it, a
reset input or valid code or TEK will be required after power up or after a fire alarm condition.
