LockState RemoteLock LS-5i - Installation Instructions; Configure Latch Backset

1
INsTALLATIONs INsTRuCTIONs
1. CONfIguRE LATCh BACKsET
The BACKSET is the distance between the center of cross
bore and edge bore of the door.



DEADBOLT BACKSET


LEVER BACKSET




Note : The shape of cam should be square.
A
A
B
B
C
C
