To Next PageTo Next PageWhat to do if Loctite CL15 UV Industrial Equipment has low UV output?
To address low UV output in Loctite Industrial Equipment, first, check the lamp's usage hours and replace it if necessary. Next, inspect the light guide's end for any polymer buildup and clean it using isopropyl alcohol. Finally, ensure the light guide is fully inserted into its receptacle.
How to troubleshoot if Loctite Industrial Equipment does not turn on?
If your Loctite Industrial Equipment unit does not turn on, begin by verifying the power supply at the wall. Then, inspect the condition of the line cord and check its connections. Lastly, examine the fuse.
What to do if the lamp fails to ignite in Loctite Industrial Equipment?
If the lamp in your Loctite Industrial Equipment fails to ignite, start by checking the lamp's usage hours and replace it if needed. Then, verify the lamp power connections.
What to do if the shutter does not open on Loctite CL15 UV Industrial Equipment?
If the shutter on your Loctite Industrial Equipment does not open, first confirm that the footswitch is properly plugged in. Next, verify that the PLC is correctly wired. Also, check that the shutter is mechanically free. Finally, ensure that the light guide is properly seated, so the safety interlock switch is engaged.
What to do if I cannot fully insert the light guide into the light guide receptacle of Loctite CL15 UV Industrial Equipment?
If you cannot fully insert the light guide into the light guide receptacle of your Loctite Industrial Equipment, back off the set screw on the side of the light guide receptacle.
General| Service Temperature Range | -40 °C to +120 °C |
|---|---|
| Shelf Life | 12 months |
| Chemical Base | Acrylic |
| Appearance | Clear |
| Cure Type | UV Light |
| Applications | Bonding, sealing |
| Key Substrates | Glass, metals, plastics |
| Color | Clear |
Defines types of emphasized information like warnings, cautions, and notices for user guidance.
Lists all components included with the Loctite CL15 UV Curing Wand System.
Details critical safety warnings and cautions for operating the UV curing unit safely.
Describes the intended use and applications for the Loctite UV CL15 Wand System.
Explains how the UV curing unit functions when switched on and during the curing process.
Details the front panel controls, LCD display, and key connections of the curing unit.
Details the back panel layout including cooling fans, power entry, and footswitch connector.
Illustrates and labels internal components of the lamp housing, including bulb, reflector, shutter, and receptacle.
Specifies voltage, frequency, auxiliary output, and fuse details for the curing unit.
Provides the physical size and weight specifications of the Loctite CL15 UV Curing Wand System.
Details the initial UV output and includes a spectral intensity graph.
Outlines the necessary clearance and environmental conditions for unit installation.
Guides the user on connecting the footswitch, power cord, and light guide.
Describes the process of turning on the unit and its warm-up sequence.
Explains how to initiate curing using a footswitch or external PLC.
Details how to access and navigate unit functions and view system/lamp hours.
Guides on configuring shutter open/close times and the number of curing cycles.
Explains how to reset the lamp hour meter and save configuration changes.
Provides cautions for handling light guides, including removing caps and avoiding bends.
Details the procedure for inserting a single light guide into the unit's receptacle.
Provides step-by-step instructions for balancing output using a radiometer.
Covers monitoring UV output, cleaning light guides, and maintaining fans.
Provides detailed, step-by-step instructions for safely replacing the UV lamp module.
Provides a table of common operating problems and their recommended corrective actions.
Illustrates the pin connections for operating the unit manually via a footswitch.
Shows the pin connections for integrating and operating the unit with a PLC.
Lists Loctite part numbers and descriptions for replacement lamps, light guides, and accessories.
Details Henkel's express warranty on materials, workmanship, and lamp life.
Outlines conditions that void the warranty and disclaims implied warranties.
