11
- If two dispense valves are used, remove blanking plug from the reservoir lid and
replace with additional reservoir/tube fitting.
4.3 Filling and Refilling the Product Reservoir
Warning!
Never fill the product directly into the reservoir!
The pneumatic and safety devices would become clogged and therefore ineffective!
Warning!
Before loosening the reservoir locking knobs (7), the EQ RC50 Integrated
Dispenser I4.0 must be depressurized (pressure-free)!
When dispensing cyanoacrylate and an empty signal is shown, refill the product
reservoir immediately, since air in the product line results in curing of the product!
Before loosening the reservoir knobs (7), the reservoir must be depressurized!
The reservoir is depressurized when the depressurizing valve (2) is in “OFF” position
and pressure gauge (5) indicates no pressure.
