18
3. Bluetooth communication function testing
• Click the Bluetooth selection button, Connect a smartphone to EQ RC50
Integrated Dispenser via Bluetooth.
• Install APP BLUTOOTHASSIST on the smartphone (Android system)
• Test command on the APP BLUTOOTHASSIT, check the status or response on
EQ RC50 Integrated Dispenser I-4.0 user Interface.
Refer to the table below for the test commands which used to remote monitor by Wi-Fi,
Bluetooth or ethernet.
Command
Keying Command
Feedback on Page
System Status Request
Command
S_STATUS
S_STATUS
Run: True
✓
Connection built
S_TEM_HUM
S_TEM_HUM
TEM:24, Hum:33
✓
Temperature:24,
Humidity: 33
S_LOW_LEVEL_STATUS
S_LOW_LEVEL_STATUS
S_LOW_LEVEL_STATUS
LOWER
✓
Same as shows on
reservoir page (See
section 5.3)
S_PRESSURE
S_PRESSURE
PRESSURE 1.50
✓
Same as shows on
reservoir page (see
section 5.3), 1.5 bar
Parameter Edit Command
W_MODE
W_MODE ON
MODE TRUE
Mode is "RUN"
W_MODE OFF
MODE FALSE
Mode is "STOP"
W_CH1_MODE
W_CH1_MODE TIMER
CH1 TIMER
✓
CH1's mode set to
TIMER, shows on page
(see section 5.3).
W_CH2_MODE
W_CH2_MODE TIMER
CH2 TIMER
✓
CH2's mode set to
TIMER, shows on page
(see section 5.3).
W_CH1_TIMER
W_CH1_TIMER 4
CH1_TIMER 4.00
✓
CH1's timer set to 4s
W_CH2_TIMER
W_CH2_TIMER 2.5
CH2_TIMER 2.50
✓
CH2's timer set to 2.5s
W_TARGET_PRESSURE
W_TARGET_PRESSURE
1.5
Target Pressure 1.50
✓
Target pressure set to
1.5
