Loewe Connect 22 SL - Wiring Diagram Xelos 32

13
Panelkit kpl.
8pol
LCD Panel 32 Z 100Hz FHD 90459.950
CN 24
50pol.
Netzteil 90462.907
PL 205
14pol
TR 200
L 100
90459.909
weiss/ schwarz
90459.909
rot/ schwarz
Signalboard
90462.901
CN 29
8pol
4pol
CN 10
CN 131
68pol.
JK 3
JK 1
JK 102
CN 3
CN 7
CN 6
CN 9
SC 1
JK 4
CN 2
TU 1
JK 8
CN 5
JK 101
Netzschalter Main switch 32370
Verdrahtungsplan / Wiring diagram Xelos 32
TP 200
~230V
PL101
Bedienteil 90462.903
8pol
CN 1
CN 8
L 102
L 101
LED Backlight
HS 200
HS 201
HS 100
TR 100
TR 300
PL 306
12pol
12pol
41pol
51pol
12pol
CN 2
1
U 16
14pol
CN 20
CN 26
41pol
51pol
