Loewe Individual 55 Compose 3D, Individual 46 Compose 3D, Individual 40 Compose 3D, Individual 32 Compose 3D Service Manual

53
SL121
Art.-Nr. Art. No. 69418 B/L80 69418 B/L/U47 69419 B/L80 69419 B/L/U47 69408 B/L/U48 69409 B/L/U48 69410 B/L/U48
Geräte-Typ
TV set type Individual 40 Selection LED 200 Individual 40 Selection LED 200 DR+ Individual 46 Selection LED200 Individual 46 Selection LED 200 DR+ Individual 40 Compose LED 400 DR+ Individual 46 Compose LED 400 DR+ Individual 55 Compose LED 400 DR+
Baugruppen • Components
Signal Board
70800
050 X X X X X
051 X X
Basic Board
70901
050 X X X X X X X
Audio Interface 70627 050 X X X X X X X
AV Double CI Interface
70480 052 X X X X X X X
Bedienteil+IR
Control Unit+IR
70701 050 X X X X X
70945 050 X X
LCD Panel Kit 40“ / 200 Hz
SA LTA400HL03 CH15
70778 001 X X X
LCD Panel Kit 46“ / 200Hz
SA LTA460HQ05 CH14
70730 001 X X X
LCD Panel Kit 55“ / 200 Hz
SA LTA550HQ03 CH16
70809 001
X
LED Backlight Treiber 70620
050 X X X
051 X
052 X X X
RJ 12 Modul 70493 050 X X X X X X X
Tuner kpl.
FET08 single
70623 052 X X
Tuner kpl.
FET08 twin
70319 055 X X X X X
Tuner kpl.
DVB-S2 twin
70286 055 X X X
Modul W-LAN SL121
70830 001 X X X
Fernbedienung Assist
Remote Control Assist
89900 A08 X X X X X X X
ARS • Retrofit Kit
Modul DVB-S2 Single 70622
080
(051)
X X
Modul DVB-S2 Twin
70286
080
(055)
X X
Modul DVB-T2/C Single 70913 080 X X
Modul DVB-T2/C Twin
70914 080 X X X X X
Modul W-LAN SL121
70830
080
X X X X
Festplatte 500GB SATA
34063 080 X X X X X
Baugruppenübersicht • Components chart
