ELECTRICAL CONNECTIONS
Connect WTS3 as follows before to supply the board.
TB1-4 TB5-8 TB9-12 TB13-16
1
GND
5
+
V
OUT
9
S
HLD
13
-
E
XC
2
GND
6
-VOUT/-IOUT
10
- SIG
14
- S
3
+24 VDC
7
SHLD
11
+ SIG
15
+ S
4
COM24
8
+IOUT
12
SHLD
16
+ EXC
Using cables and load cells LOGIC Srl refer to the following table the correspondence between the
color codes Logic and signals of the load cell.
SIGNAL
DESCRIPTION
EXTENSION CABLE
CAB-TS6
LOAD CELL
CABLE
+ Exc
+
E
XCITATION
Red
Red
- Exc
- EXCITATION
Blue
Black
+S
+ SENSE
Green
--
- S
- SENSE
Grey
--
+ Sig
+ SIGNAL
White
Green
- Sig
- SIGNAL
Yellow
White
Shld
SHIELD
Shield + Cont. Wire
Yellow / Shield
