HDMI2.0 4x1 Switcher
www.logicav.in 10
The interface of the control software is shown as below:
Please set the parameters of COM number, bound rate, data bit, stop bit and the parity
bit correctly, then the RS232 commands can be sent in Command Sending Area.
Baud rate: 9600;
Data bit: 8;
Stop bit: 1;
Parity bit: none.
Parameter configuration area
Monitoring area, indicates if the
command sent works.
