Logic LG-HSW401-4K

HDMI2.0 4x1 Switcher
www.logicav.in 11
7.2 RS232 Command
Note: All commands must be ended with “<CR><LF>”.
7.2.1 Signal Switching
Function
Command
Feedback Example
Switch to HDMI input 1.
>>HDMI1
<<HDMI1
Switch to HDMI input 2.
>>HDMI2
<<HDMI2
Switch to HDMI input 3.
>>HDMI3
<<HDMI3
Switch to HDMI input 4.
>>HDMI4
<<HDMI4
Enable auto-switching mode.
>>AUTO
<<AUTO Switch
Enable manual switching mode.
>>MANUAL
<<MANUAL Switch
7.2.2 Source Device Control
Note:
 The input source device is required to support CEC.
 Due to the HDMI input 4 port does not support CEC, the source device connected to
this port can not be controlled by IR remote.
Function
Command
Feedback Example
Turn on the input source device,
e.g. Blue-ray DVD.
>>SRCOn
<<SRCOn
Turn off the input source device,
e.g. Blue-ray DVD.
>>SRCOff
<<SRCOff
Play
>>SRCPlay
<<SRCPlay
Pause
>>SRCPause
<<SRCPause
Stop
>>SRCStop
<<SRCStop
Fast Forward x1
>>SRCForward
>>SRCForward
Fast Rewind x1
>>SRCBackward
<<SRCBackward
Next Section
>>SRCSkipForward
>>SRCSkipForward
