ML350G-10 Industrial Computer

6.1 - Jumpers and Headers Guide

Number Location Function

1 J1_BIOS BIOS Load Default Header/Clear CMOS

2 J2 LAN1Connector

3 J3 LAN2Connector

4 J4 DisplayPort 1

5 J5 DisplayPort 2

6 J6 USBTypeCConnector

7 J7 USB 3.0 Connector

8 J8 Audio Connector

9 J9_CEC CECHeader

10 J10 USB 2.0 Connector

11 J11 USB 2.0 Connector

12 J12_USB USB 2.0 Header

13 J13_AT_ATX AT/ATXModeJumper

14 J14_PCIE Mini PCIe (PCIe+USB)

15 J15_MUX MiniPCIe(PCIe+SATA+USB)

16 J16_SATA mSATA(SATA+USB)

17 J18_Power_In 4 Pin Power Connector

18 J20 DC In

19 J21_SATA SATAPowerHeader

20 J22_FAN FANHeader

21 J23_AMBIENT Ambient Sensor Header

22 COM1 Serial Port 1 Header

23 COM2 Serial Port 2 Header

24 XBT1_BATTERY Coin Battery Header

25 XBT2_BATTERY Coin Battery Header

26 SO_DIMM1 Memory Slot

27 DEBUG Debug Header
