6.2 - Conguring Jumpers
Refertothefollowingdiagramsforconguringjumpersandonboardheaders.
J1_BIOS
TheJ1_BIOSjumperloadsthedefaultBIOSsettings.Shortpins2-3fornormaloperation.Shortpins1-2to
cleartheCMOSandresetthesystemsetupcongurationtodefaultsettings.Ifyouexperiencechallenges
powering up, short pins 1-2 to troubleshoot.
J13_AT_ATX
AT=Autopoweron.
ATX=Noautopoweron.
Clear CMOS Normal
AT Mode ATX Mode
