31
Care and Use
To clean the radio
• Use a soft, damp cloth
• Do not immerse in water.
• Do not use spirits or cleaning solvents.
If the radio gets wet
• Turn the 2 way radio off and remove the batteries.
• Dry with a soft cloth.
• All battery elements may be wiped with a dry, lint-free cloth.
• Do not use the radio while it is not completely dry.
Technical Specifications Frequency List PMRU6
Channels : 8 1. 446.00625
Operating frequency : 446.00625-446.09375 MHz 2. 446.01875
Conversation range : 3 km maximum 3. 446.03125
Power supply : 3 AAA alkaline batteries 4. 446.04375
5. 446.05625
Transmission power (Watts) : 0.5 PAR 6. 446.06875
7. 446.08125
Channel separation (kHz) : 12.5 8. 446.09375
English
