10
-pole input terminal and tube core
+ pole input terminal and tube core
Strip the cable, insert it into tube core and press it firmly with a crimping plier
Step 2: Loosen the terminal cap and lead cable through the cap. Insert tube core into wire slot until the connection is
completed.
Step 3: Tighten the terminal cap.
