LogicPower EA33KTLSI - Page 28

28
Output AC short-circuit protection
Yes
AC overload, overcurrent restriction and
protection
Yes
Overvoltage, undervoltage and unbalance
protection for power grid
Yes
Overfrequency and Underfrequency protection
Yes
Electric leakage protection
Yes
Lightning protection
Yes
Islanding protection
Active and passive method
DC surge protection
Yes
AC surge protection
Yes
Insulation impedance detection protection
Yes
Standards
Certification
TUV/VDE/CE/CQC
Grid-connected standards
TUV / VDE – AR – N – 4105 / G59
EMC / Safety rules
EN61000-6-2,EN61000-6-3,
EN61000-3-2,EN61000-3-3,
EN61000-3-11,EN61000-3-12,
EN/IEC62109-1,EN/IEC62109-2
Display and communications
Display
LED
RS485
Yes
USB
Yes
PLC
Optional
APP & BLE
Yes
Others
Mechanical dimensions (W×H×D)
580 mm × 820 mm × 255 mm
Operating temperature
-25℃ ~ 60℃
Heat dissipation method
Natural heat dissipation
Maximum working altitude
3000 m
Relative humidity
0 - 100% (non-condensing)
Weight
< 65 kg
Protection rating
IP 65
