8
Wall Mounting (optional)
1. Mark two points on the wall that are 80mm apart to lay the fixing
centres as shown below.
Wall
Wall plug
Screw
80mm
wall mount slots
2. Drill holes in the wall.
3. Insert the wall plugs into the holes.
4. Drive in the screws and make sure to leave approximately 5mm of the
screw head from the wall to hold the base unit securely.
5. Hang the base unit on the screws using the wall mount slots.
Before you drill any holes, make sure there is no electrical wiring or pipes hidden
in the wall.
