5
Unpacking
Remove all packaging from the unit. Retain the packaging. If you dispose of it please do so according to
local regulations.
The following items are included:
The Main Unit
Thank you for purchasing your new Logik Washer Dryer.
We recommend that you spend some time reading this installation/instruction manual
in order that you fully understand all the operational features it offers.
Read all the safety instructions carefully before use and keep this installation/
instruction manual for future reference.
If items are missing or damaged please contact Partmaster (UK only).
Tel: 0844 800 3456 for assistance.
Water Supply Hose
P.N.: 0020300158A
U-Shape Holder
P.N.: 00221123015002
Noise Protection Board (includes
the feather felt)
P.N.: 00213400001800A
Cover Cap x 3
P.N.: 00221153000008
Instruction Manual
P.N.: L612S_WD12-003
Wash
Delay Extra rinse Dry Start/Pause
Speed
Temp
Quickwash
Wash
Rinse
Spin
ONOFF
Dry
Iron
Air wash
Wool
Synthetics
Cotton&Linen
Prewash
Rinse Spin Dry
Time
This product has been wet tested to
ensure correct operation. As a result some
water may remain inside the unit. This
is normal and safe. Remove any water
droplets from the exterior if necessary.
L612S_WD12_IB_120627_RC_Pauline.indd 5 28/06/2012 10:00 AM
