10
10. Carefully set the upper door back into place.
Re-attach the re-assembled upper door hinge
on the opposite side of the unit. Ensure the
fridge door is aligned horizontally and vertically
so that the seals are closed on all sides before
nally tightening the top hinge.
12. Put the top cover back on and x it in place with
the screws.
13. With the door closed, check that the door is
aligned horizontally and vertically and that
the seals are closed on all sides before nally
tightening the bottom hinge. Re-adjust the
levelling feet as needed.
unscrew screw
180˚
11. On the top panel move the blanking plate to the
side opposite the hinge.
9. Remove and replace the pin on the reverse side
of the hinge.
LFC152W14_IB_Final140122.indd 10 22/01/2014 9:16 PM
