9
5. Remove the lower screws, hinge bracket and
levelling foot from the unit bottom. Keep the
matching bracket and foot together.
unscrew unscrew
6. Remove the remaining levelling foot from the
other side of the unit bottom and transfer it to
the corresponding position on the opposite side
of the unit bottom.
unscrew
screw
180˚
7. Re-attach the bottom door hinge, screws and
foot to the opposite side of the unit.
8. After replacing the freezer door, screw the
middle hinge back onto the opposite side of the
unit.
Middle hinge
Ensure the freezer door is aligned
horizontally and vertically, so that the
seals are closed on all sides before
nally tightening the hinge.
