8. Place the fixing plate on the opposite
side of the appliance, secure it with three
bolts, and screw the foot into position.
9. Remove the handle covers and screws
which fix the handle on the right side of
door, then remove the handle and rotate
180 degree, position on the right side, fix
it by screws and cover the handle cover.
10. With the door closed, check that the
door is aligned horizontally and vertically
and that the seals are closed on all sides
before finally tightening the bottom
hinge. Re-adjust the levelling feet as
needed.
Levelling the Unit
To do this adjust two levelling feet at the front of the unit.
If the unit is not level, the door and magnetic seal
alignments will not be covered properly.
* All images are for reference only; please refer to your individual unit for actual item.
