25
5. Unscrew and remove the bottom hinge
pin, turn the bracket over and replace it.
unscrew
screw
screw
screw
6. Re-fit the the bottom hinge. Replace
both levelling feet.
7. Place the door back on. Ensure the door
is aligned horizontally and vertically
so that the seals are closed on all sides
before finally tightening the top hinge.
LUF55W18E_IB_5L_RC_190415_grace.indb 25 15/4/2019 4:53 PM
