2. Description
2.1 Model Nomenclature
Record your Laser Meter’s complete Model Number here:
LM-SD - ___________
Base Model
Power Input
24: 24VDC
110: 110VAC
Serial Number _________________
Figure 2.1: Model Number
2.2 Specifications
Accuracy
±3mm within 30m
Resolution
0.1 mm
Laser
650nm Visible red, <1mW Class II, 0.6 mrad scattering
Detect Range
0.2-100m Reflector needed between 30m and 100m
Response
Relay < 320 ms, PNP < 300ms
Operating Temp
-10˚C to +50˚C (14˚F to +122˚F). With water cooling: +110˚C (230˚F)
Storage Temp
-10˚C to +70˚C
Output
Relay NO/NC 125VAC @ 0.3A, PNP type output 24VDC @300mA,
Analog Output
4-20mA @ ≤500Ω Accuracy: ±0.15%
Temp Drift
<50ppm/˚C
Power Input
24VDC ±10% <1.5W
Cable
Insulation 20MΩ, 500VDC, ≥500˚C (930˚F)
Housing
Hermetically sealed cast aluminum enclosure rated IP65, includes cooling
water connections and air purge.
Size
Enclosure; 280 mm L x 89 mm D x 300 mm H (with mounting bracket)
Weight
6kg (13.3 lbs)
