3.2 Sensor Mounting
Mounting Bracket- The LM-SD has an adjustable mounting foot designed to allow easy
rotation through horizontal and vertical axes. The sensor is fixed to the support with a
single 18 mm bolt through the LM-SD’s base mounting stand. The altitude angle may be
changed by slightly loosening the three cap screws in the base with a 4mm Allen key,
adjusting to the correct angle and retightening the same three screws. The support must be
sufficiently rigid to absorb any excessive site vibrations that could affect the precision
output of the detector.
Air, Cooling Water Fittings- The LM-SD has a water-cooling jacket to keep the electronics
within their operating temperature range, and an air-purged hood for protection of the
window glass. These sensors can thus be used in harsh environments with high
temperatures, steam, dust, and smoke. Please see Section 4.2 Plumbing Connection and
Section 4.3 Air-Purge Connection for further details on installing these protections for your
sensor.
Caution- For installation in environments that may include excessive water vapor or smoke,
it is recommended that additional ventilation such as air curtains or fans be used to clear
the area so the sensor can “see” the target.
