Logika Technologies Inc. Model LM-SD Operator’s Manual Rev. 11-2010
Web: www.logikatech.com Phone: 905-829-5841 Fax: 905-829-8787 Email: info@logikatech.com
P a g e | 7
4. Utility Connections
4.1 Electrical Connections
Electrical Overview- All electrical connections (power and signal) to the LM-SD are made via
a 15-pin Harting style connector with ground. The sensor is supplied with a mating
connector at the back of its enclosure and a standard 2-meter cable with the quick-connect
assembly mating to the sensor and bare wire terminals for the junction box connections.
Other cable lengths are available from Logika Technologies upon request.
