LogTag UTRIX Work Instruction Manual Revision 1.07 MP Release Page 19/52
1.9 Mount PCB in rear case
Sealant options: Dow Corning 3140 Non corrosive RTV sealant.
Non-acid cure RTV is required.
Procedure:
1. Apply a small amount of Sealant with syringe into the slot shown:
2. Place PCBA into Rear Case as shown, press down to the right and left of each PCBA mounting hole
to retain the PCBA in the case.
