LogTag UTRIX Work Instruction Manual Revision 1.07 MP Release Page 24/52
2.2 Add sealant to crystal & case
Sealant options: Dow Corning 3140 Non corrosive RTV sealant.
Non-acid cure RTV is required.
Procedure:
1. Apply Sealant with syringe over the crystal, crystal legs and pads, C2, C3
2. Apply a small amount of Sealant with syringe into the slot shown (near USB port):
