Instructions for use Lojer Modux nursing bed / Version 2.5
Copyright © Lojer Oy, 2022 17
Image 21. Power cord end
2. Remove the peg and pin, which are removable only from the foot end of
the bed.
Image 22. Peg and pin
3. Pull the slides out of the bar. Observe the position and order of the slides!
Image 23. Slides
4. Insert the slide pegs into the holes at the other end of the side rail. Make
sure not to change the position or order of the slides!
5. Lift the side rail onto the bar and make sure it locks in the top position.
6. NB! If order of the slides change, the side rail can’t be raised to high
position without pressing side rail release -button (see image 32). Order
and position of the slides is correct, when it is possible to lift the side rail
up by lifting from side rails’ handle.
