6.5 Wheel systems
In nursing bed two different type wheel systems are used. Individual or dual
locking wheel systems. In individual wheel system every wheel must be
locked or released separately. In dual wheel system, both wheels at the same
end are locked at the same time, however, so that the wheels at the foot and
head end must be locked separately.
6.5.1 Individually locking wheels
Lock the wheel by pressing pedal down. When pedal is up, the wheel is
unlocked. Each wheel must be locked separately and all wheels must be
locked to ensure that bed remains stationary.
1 Wheel unlocked
2 Wheel locked
Image 25. Locking wheels, individual locking wheels
6.5.2 Dual locking system for wheels
In dual locking wheel system, head- or foot end wheels can be locked
simultaneously by pressing brake lever down from either side of the bed. Use
of dual locking system is easier when bed is located close to wall and it would
be difficult to access brake lever on wall side. To lock wheels, press lever
down, to release wheel brake, raise lever to horizontal position. All wheels
must be locked to ensure bed remains stationary.
Image 26. Dual locking, lever down, brake on, lever up, brake off.
Remember to lock all wheels in bed, head- and foot end and both
sides of bed wheels. Each wheel must be locked separately, depending
of the used wheel system!
