WIRING DIAGRAMS
-36-
Engine Type with Oil Alert and Without Electric Starting
Bl BLACK
Y YELLOW
G GREEN
TRANSISTORIZED
IGNITION UNIT
SPARK
PLUG
OIL ALERT UNIT
OIL LEVE
L
SWITCH
ENGINE
SWITCH
Bl
Y
Y
Y
Bl
