LONCIN G200F Shop Manual

G120F/G160F/G200F Part IV Disassembly and maintenance
- 34 -
Reassembly steps
1) Wind the spring into the cover and hook
spring’s outer hook to the notch of the spring
cover.
2) Align the spring’s outer hook with reel’s groove, and
install the cover onto the reel.
3) Grease the tab on the starter case. Install the starter
reel and turn the starter reel leftward to hook the inner
hook to the tab on the starter case.
4) Make a figure eight knot at the rope end, feed the
other end through starter reel’s rope hole and pull
the rope out of the hole by a certain length. Then
turn starter reel counterclockwise five turns.
Return spring
Spring cover
Starter case
Sp
ring
cover
Put spring’s outer
hook securely into
reel groove.
Starter reel
Starter case

LONCIN G200F Specifications

General

Displacement	196 cc
Compression Ratio	8.5:1
Fuel System	Carburetor
Starting System	Recoil start
Weight	16 kg
Fuel Type	Unleaded gasoline
Lubrication System	Splash
Engine Type	Forced air-cooled, 4-stroke, OHV, single cylinder
Bore x Stroke	68 mm x 54 mm
Max Power	6.5 HP (4.8 kW) / 3600 rpm
Ignition System	Transistorized magneto ignition
Fuel Tank Capacity	3.6 L
Oil Capacity	0.6 L
