LONCIN G200F Shop Manual

G120F/G160F/G200F Part IV Disassembly and maintenance
- 35 -
5) Feed the rope through the starter case hole and the
starter grip; then make a figure eight knot at the rope
end.
6) Assemble the ratchets and then tighten them with
special bolts.
Pay special attention to the installation direction of
the ratchets.
7) Check the operation of the ratchet by pulling the
starter rope out several times.
Starter case hole
Grip
M5×10 special bolt
Apply thread locking
agent
Ratchet
Reel cover
Friction spring
Grease the inner side
Ratchet
Ratchet
Ratchet spring

LONCIN G200F Specifications

General

Displacement	196 cc
Compression Ratio	8.5:1
Fuel System	Carburetor
Starting System	Recoil start
Weight	16 kg
Fuel Type	Unleaded gasoline
Lubrication System	Splash
Engine Type	Forced air-cooled, 4-stroke, OHV, single cylinder
Bore x Stroke	68 mm x 54 mm
Max Power	6.5 HP (4.8 kW) / 3600 rpm
Ignition System	Transistorized magneto ignition
Fuel Tank Capacity	3.6 L
Oil Capacity	0.6 L
